StarTech.com 2-Port 10G PCIe Network Card - PCI Express 10GBASE-T & NBASE-T NIC with Intel-X550AT Chipset 10/5/2.5/1GbE - Multi

This internal network card installs in a PCI Express slot to add two RJ45 Ethernet ports to servers or workstations. It features the Intel-X550AT chipset and provides wired connectivity with support for multiple speeds: 10 GbE, 5 GbE, 2.5 GbE, 1 GbE, and 100 Mbps. Its design allows for expanding network bandwidth without replacing existing cabling infrastructure, being compatible with 10GBASE-T and NBASE-T specifications.

The device is compatible with Linux and works with various operating systems. To achieve the maximum speed of 10,000 Mbit/s, Cat6a cables are required, while lower speeds support Cat5e cabling. NBASE-T technology enables 2.5 Gbps or 5 Gbps connections over Cat5e infrastructure up to 100 meters. Its dimensions are 15 mm wide, 132 mm high, and 228 mm deep, with a weight of 0.098 kg and a black finish.

• Two RJ45 ports with Intel-X550AT chipset
• Support for 10/5/2.5/1 GbE and 100 Mbps speeds
• Compatibility with 10GBASE-T and NBASE-T specifications
• Internal installation via PCI Express interface
• Compatible with Linux operating systems
