WP Keystone Cat. 6a UTP RJ45/Female

This Cat. 6a UTP Keystone jack allows for the termination of network cables using an 8P8C RJ45 female connector. It is designed to support transmissions of up to 500 MHz and 10GBase-T applications, complying with ISO/IEC 11801, ISO/IEC 60603-7, and ANSI/TIA 568-C.2 standards. Its design facilitates tool-free installation, incorporating an included cable strain relief to ensure proper fixation.

The connector body is made of ABS UL 94V-0 material, while the conductor plate is FR4 with a thickness of 1.2 mm. It accepts IDC cables from 22 to 26 AWG, both solid and stranded. The component supports more than 750 mating cycles and 200 clamp cycles, operating in a temperature range of -40 °C to +68 °C.

• Support for transmissions up to 500 MHz and 10GBase-T
• Tool-free installation with included cable strain relief
• Compatible with 22 to 26 AWG solid and stranded IDC cables
• Compliance with ISO/IEC 11801 and ANSI/TIA 568-C.2 standards
• ABS UL 94V-0 body and 1.2 mm FR4 conductor plate
• Operating temperature range of -40 °C to +68 °C
