This Hikvision network video recorder is designed to manage IP video surveillance systems with up to 8 channels. It features a LAN port and eight PoE ports that allow cameras to be powered and connected directly, with a total power output of up to 75 W compliant with the IEEE 802.3af/at standard. The device supports recording resolutions of up to 8 MP and video decoding in H.265+, H.265, H.264+, and H.264 formats, optimizing storage and data transmission.
Regarding connectivity and playback, it includes an HDMI output with 4K resolution (3,840 × 2,160) and a VGA output (1,920 × 1,080), as well as RCA audio inputs and outputs and two USB 2.0 ports. It allows synchronous playback of all 8 channels and decodes 4 channels at 1080p. Its 1U form factor chassis includes a SATA port for drives up to 8 TB. It operates with a 48 VDC power supply, consumes less than 10 W, and functions in temperatures ranging from -10 to 55 °C.
- 8-channel IP video input
- 8 RJ-45 PoE ports with total power ≤ 75 W
- 4K HDMI output (3,840 × 2,160) and VGA output (1,920 × 1,080)
- Support for H.265+/H.265/H.264+/H.264 encoding
- Recording up to 8 MP and synchronous playback of 8 channels
- 1U chassis with SATA port for drives up to 8 TB
