This Hikvision video surveillance camera features a 1/3" progressive scan CMOS image sensor that achieves a maximum resolution of 2560 × 1440 pixels. Its 2.8 mm fixed focal length lens offers a horizontal field of view of 99°, vertical of 55°, and diagonal of 116°, with an aperture of F2.0. The device includes infrared illumination with a range of up to 30 meters, allowing for black-and-white recording in total darkness, while color operation requires a minimum illumination of 0.01 lux.
The unit integrates 120 dB WDR technology and a signal-to-noise ratio greater than 52 dB, along with image enhancement functions such as BLC, HLC, and 3D noise reduction. It supports four programmable polygonal privacy masks and allows adjustment of parameters such as brightness, contrast, and white balance via software or web browser. Video compression supports H.265+, H.265, H.264+, and H.264 codecs, with bit rates from 32 Kbps to 8 Mbps. Connectivity is provided through a self-adaptive 10 M/100 M RJ45 Ethernet port, and power is supplied by 12 VDC.
- Maximum resolution of 2560 × 1440 pixels
- 2.8 mm fixed lens with F2.0 aperture
- Infrared night vision up to 30 meters
- Wide Dynamic Range (WDR) of 120 dB
- H.265+ and H.264+ video compression
- 10 M/100 M RJ45 Ethernet connection
